📝 Abstract
In this guide, I demonstrate the complete lifecycle of working with AWS EC2 and EBS volumes starting from launching an EC2 instance and attaching a new EBS volume, to preserving data by disabling delete-on-termination.
You’ll also learn how to:
Recover EBS data after EC2 termination
Migrate EBS volumes across Availability Zones using snapshots
Copy snapshots across AWS Regions to restore data remotely
This end-to-end workflow ensures data durability, flexibility, and disaster recovery readiness for modern cloud infrastructure setups.
✅ Step 1: Launch an EC2 Instance
To begin, launch a new EC2 instance:
Go to the EC2 Dashboard in AWS Management Console.
Click on “Launch Instance”.
Select an appropriate AMI (Amazon Machine Image), such as Ubuntu or Amazon Linux.
Choose an instance type (e.g., t2.micro for testing or t3.medium for production).
In the network section, you can keep the default VPC and Subnet settings — AWS will automatically manage networking unless you have a custom setup.
Continue with key pair, storage, and security group settings.
Once launched, the EC2 instance will automatically have a root EBS volume attached.
🔒 Understanding the “Delete on Termination” Setting in EC2
When launching an EC2 instance, AWS automatically attaches a root EBS volume to store the operating system and configuration files. By default, this root volume is deleted when the instance is terminated — but you can control this behavior.
📌 Why it's important to uncheck “Delete on Termination”:
🔐 Preserve critical data: Prevents the root EBS volume from being deleted, even if the EC2 instance is terminated.
🔄 Easily recover configuration: Retain OS setup, logs, and installed packages for later use or migration.
💼 Safe for production use: Especially helpful in staging or production environments where instance termination is temporary or planned.
☁️ Avoid accidental data loss: Ensures your volume (and its data) remains available in the EBS → Volumes section after termination.
🔧 Attach to a new EC2: The preserved volume can be re-attached to any EC2 instance in the same Availability Zone for instant recovery.
As shown below, AWS automatically creates and attaches a root EBS volume when you launch an EC2 instance.
✅ Step 2: Create and Attach a New EBS Volume to Your EC2 Instance
After launching your EC2 instance, you may need extra storage. For that, you can create a new EBS volume and attach it.
🔧 Steps to Create:
Go to EC2 → Elastic Block Store → Volumes → Create Volume
Select Volume Type, Size, and most importantly, choose the same Availability Zone as your EC2 instance
📌 EBS volumes can only be attached to EC2 instances in the same Availability Zone
🔗 Steps to Attach:
After creation, select the volume → Click Actions → Attach Volume
Choose your EC2 instance and confirm the device name (e.g., /dev/xvdf)
Click Attach — your volume is now connected to the instance
✅ You’ll now need to format and mount the volume inside the EC2, which we’ll do in the next step.
✅ Our new EBS volume has been successfully created and is now ready to be attached to the EC2 instance.
📌 Go to Actions → Attach Volume, then select your EC2 instance to attach the volume.
✅ Step 3: Connect to EC2 and Mount the Attached EBS Volume
Once your EBS volume is attached, you need to connect to your EC2 instance and prepare the volume for use.
💻 Steps to Check and Mount:
SSH into your EC2 instance using terminal or any SSH client
(e.g., using .pem key file)
Run the following to verify attached volumes:
lsblk
sudo mkfs -t ext4 /dev/xvdd
mkfs: Stands for “make file system” — used to format the disk.
-t ext4: Specifies the ext4 file system type (widely used in Linux).
/dev/xvdd: The name of the newly attached EBS volume.
📌 This command prepares the volume for storing files by formatting it.
📁 Step 5: Create a Mount Point
sudo mkdir /mydata
📌 This is where your EBS volume will be accessible from.
🔗 Step 6: Mount the Volume
sudo mount /dev/xvdd /mydata
mount: Command to attach the volume to a directory.
/dev/xvdd: The formatted EBS volume.
/mydata: The directory where the volume will be mounted.
📌 This makes the volume usable like a local disk through /mydata.
📊 Step 7: Verify the Mount Status
df -h
📌 This helps confirm whether the EBS volume is mounted and shows its usage.
📝 Step 8: Write Data into the Mounted Volume
echo "This is task for EBS performed by Apurv Gujjar" | sudo tee /mydata/ebs-test.txt
echo: Prints the given message.
| sudo tee: Pipes the message into a file with root permissions.
/mydata/ebs-test.txt: The file to create inside the mounted volume.
📌 This command creates a test file in the EBS volume to validate it's writable.
🔍 Step 9: Check Stored Data
ls /mydata
cat /mydata/ebs-test.txt
📌 Confirms the file contains the correct data you wrote earlier.
